onecranes D2C / D2H DynaHoist Vector II Inverter – Full Series

Overview

Konecranes D2C (Travel) / D2H (Hoist) Vector II is the original heavy‑duty frequency inverter series designed exclusively for industrial cranes. Built for hoist and trolley motions, it delivers precise vector control, independent speed supervision (SSU), integrated brake control, and robust protection for harsh environments.

Original Konecranes genuine quality, full series available.

Full Series Models

F‑Series (380–500 VAC)

D2C (Travel): 002F, 003F, 004F, 005F, 007F, 011F, 015F, 018F, 022F, 030F, 037F, 045F, 055F, 075F, 090F, 110F, 132F, 160F, 200F, 250F, 315F, 355F

D2H (Hoist): 002F, 003F, 004F, 005F, 007F, 011F, 015F, 018F, 022F, 030F, 037F, 045F, 055F, 075F, 090F, 110F, 132F, 160F, 200F, 250F, 315F, 355F

K‑Series (525–690 VAC)

D2C (Travel): 002K, 003K, 004K, 005K, 007K, 011K, 015K, 018K, 022K, 030K, 037K, 045K, 055K, 075K, 090K, 110K, 132K, 160K, 200K, 250K, 315K, 355K, 400K

D2H (Hoist): 002K, 003K, 004K, 005K, 007K, 011K, 015K, 018K, 022K, 030K, 037K, 045K, 055K, 075K, 090K, 110K, 132K, 160K, 200K, 250K, 315K, 355K, 400K

Key Features

• Crane‑optimized vector control (open‑loop / closed‑loop)

• Independent SSU speed supervision: overspeed, stall, speed‑difference protection

• Integrated DC brake control: REC12 (002–011F), ESD141 (015–132F / 002–160K)

• Built‑in braking chopper & resistor control

• Extended Speed Range (ESR) for light loads

• SSU hardware safety, independent of software

• Encoder / sensor bearing / proximity switch feedback options

• EMC category C3 / C4 for industrial environments

• Heavy‑duty enclosure, dust & vibration resistant

Technical Specifications

Material & Magnetic Info

• Main housing: Galvanized steel + painted metal

• Internal: Steel, aluminum, copper, electronic components

• Magnetic: No permanent magnets. Only passive ferrous parts. No active magnetism.

• Air / sea shipment safe, no magnetic impact.

HS Code (Export)

85044099 – Other static converters (crane frequency inverters)

Applications

• Overhead bridge cranes

• Gantry cranes

• Port / container cranes

• Steel mill & heavy industry cranes

• Hoist units & trolley drives

Package & Shipping

• Export wooden / plywood box

• Anti‑vibration foam + moisture protection

• Labeled with model, serial, weight, dimensions

• Global air / sea / truck shipping available

Why Buy from Qinmao Crane?

• 100% genuine Konecranes original

• Full series in stock / fast lead time

• Competitive pricing

• Worldwide delivery

• Technical support & after‑sales service

Contact us for model, price, lead time & quotation.
